GIGABYTE B560M DS3H PLUS 10th and 11th Gen Micro ATX Motherboard

Original price was: ৳ 14,100.00.Current price is: ৳ 13,800.00.

Highlighting Features

  • Model: B560M DS3H PLUS
  • Supported CPU: 11th/10th Gen Intel Core Processors (LGA1200)
  • Supported RAM: 4 x DIMM, up to 128GB DDR4 4600(O.C.)
  • Graphics Output: 1 x DVI-D, 1 x DisplayPort, 1 x HDMI
  • Features: 2x M.2 Slots, Realtek GbE LAN chip
Compare
* অনলাইন থেকে প্রডাক্ট অর্ডার এর পূর্বে হেল্পলাইন থেকে স্টক এবং ডেলিভারী সম্পর্কে সঠিকভাবে জেনে অর্ডার করার জন্য বিশেষভাবে অনুরোধ করা হচ্ছে *
Get the Best Deal

GIGABYTE B560M DS3H PLUS 10th and 11th Gen Micro ATX Motherboard Price in Bangladesh | BD

GIGABYTE B560M DS3H PLUS 10th and 11th Gen Micro ATX Motherboard Price in Bangladesh | BD is 13800 Tk.  You can buy any motherboard at the best price from our official website or visit our showroom.

Visit our Facebook Page or to see more offers visit our Offers Page

To see more product unboxing and first impression videos you can checkout our Official Youtube Channel

Specification

Basic Information
Supported CPU 11th Generation Intel Core i9 processors / Intel Core i7 processors / Intel Core i5 processors
10th Generation Intel Core i9 processors / Intel Core i7 processors / Intel Core i5 processors / Intel Core i3 processors/ Intel Pentium processors / Intel Celeron processors*
* Limited to processors with 4 MB Intel® Smart Cache, Intel Celeron G5xx5 family.
L3 cache varies with CPU
Chipset Intel B560 Express Chipset
BIOS 1 x 256 Mbit flash
Use of licensed AMI UEFI BIOS
PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
Form Factor Micro ATX Form Factor; 24.4cm x 24.4cm
Audio Realtek Audio CODEC
High Definition Audio
2/4/5.1/7.1-channel
Expansion Slots
PCI 1 x PCI Express x16 slot, running at x16
(The PCIEX16 slot conforms to PCI Express 4.0 standard.)*
* Supported by 11th Generation processors only.
2 x PCI Express x1 slots
(The PCIEX1 slot conforms to PCI Express 3.0 standard.)
Memory
Type DDR4
Slots 4 x DDR4 DIMM
Supported Memory 11th Generation Intel Core i9/i7/i5 processors:
Support for DDR4 4600(O.C.) / 4500(O.C.) / 4400(O.C.) / 4300(O.C.) / 4266(O.C.) / 4133(O.C.) / 4000(O.C.) / 3866(O.C.) / 3800(O.C.) / 3733(O.C.) / 3666(O.C.) / 3600(O.C.) / 3466(O.C.) / 3400(O.C.) / 3333(O.C.) / 3300(O.C.) / 3200 / 3000 / 2933 / 2800 / 2666 / 2400 / 2133 MHz
10th Generation Intel Core i9/i7 processors:
Support for DDR4 2933/2666/2400/2133 MHz memory modules
10th Generation Intel Core i5/i3/Pentium/Celeron processors:
Support for DDR4 2666/2400/2133 MHz memory modules
Maximum Memory Up to 128 GB (32 GB single DIMM capacity) of system memory
Graphics
Graphics Integrated Graphics Processor-Intel HD Graphics support:
1 x DVI-D port, supporting a maximum resolution of 1920×1200@60 Hz
* The DVI-D port does not support D-Sub connection by adapter.
1 x DisplayPort, supporting a maximum resolution of 4096×2304@60 Hz
* Support for DisplayPort 1.2 version and HDCP 2.3
1 x HDMI port, supporting a maximum resolution of 4096×2160@30 Hz
* Support for HDMI 1.4 version and HDCP 2.3.
Connector & Ports
HDMI 1 x HDMI port
Display Port (s) 1 x DisplayPort
DVI-D (s) 1 x DVI-D port
USB (s) 1 x USB Type-C port on the back panel, with USB 3.2 Gen 1 support
5 x USB 3.2 Gen 1 ports (3 ports on the back panel, 2 ports available through the internal USB header)
4 x USB 2.0/1.1 ports available through the internal USB headers
Chipset+USB 2.0 Hub:
2 x USB 2.0/1.1 ports on the back panel
LAN Port (s) Realtek GbE LAN chip (1 Gbps/100 Mbps)
Supported Storage CPU:
1 x M.2 connector (Socket 3, M key, type 2260/2280/22110 PCIe 4.0 x4/x2 SSD support) (M2P_CPU)*
* Supported by 11th Generation processors only.
Chipset:
1 x M.2 connector (Socket 3, M key, type 2260/2280 SATA and PCIe 3.0 x4/x2 SSD support) (M2A_SB)
6 x SATA 6Gb/s connectors
* Refer to “1-7 Internal Connectors,” for the installation notices for the M.2 and SATA connectors.
Intel Optane Memory Ready
Audio 3 x audio jacks
Internal I/O Ports 1 x 24-pin ATX main power connector
1 x 8-pin ATX 12V power connector
1 x CPU fan header
3 x system fan headers
1 x addressable LED strip header
1 x RGB LED strip header
6 x SATA 6Gb/s connectors
2 x M.2 Socket 3 connectors
1 x front panel header
1 x front panel audio header
1 x USB 3.2 Gen 1 header
2 x USB 2.0/1.1 headers
1 x serial port header
1 x parallel port header
1 x Clear CMOS jumper
1 x Q-Flash Plus button
TPM (Trusted Platform Module ) 1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0 module only)
Others
Special Features Support for APP Center
* Available applications in APP Center may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications.
@BIOS
EasyTune
Fast Boot
Game Boost
ON/OFF Charge
RGB Fusion
Smart Backup
System Information Viewer
Support for Q-Flash Plus
Support for Q-Flash
Support for Xpress Install
Bundled Software Norton Internet Security (OEM version)
Realtek Gaming LAN Bandwidth Control Utility
Warranty Information
Manufacturing Warranty 3 years

Description

GIGABYTE B560M DS3H PLUS 10th and 11th Gen Micro ATX Motherboard

GIGABYTE B560M DS3H PLUS Motherboard provides you with access to an LGA 1200 socket, allowing you to equip your rig with 10th and 11th Gen Intel processors. You can install up to 128GB of DDR4 RAM with four dual-channel DIMM slots and install up to two PCIe NVMe solid-state drives, enhancing the overall speed of your system suitable for gaming or running multiple applications simultaneously. Six SATA III ports allow you to install an array of compatible drives for primary or secondary storage systems. GIGABYTE B560M DS3H PLUS Motherboard comes with one PCIe 4.0 x16 and two PCIe 3.0 x1 slots, so you can install a wide range of graphics and utility cards to expand the flexibility of your system. USB 3.2 Gen 1 and USB 2.0 ports provide you with various connections for resource-demanding and low-powered peripherals, respectively. Additionally, a Gigabit Ethernet port is available, giving you quick access to wired networks to enjoy media, access the company intranet, and participate in competitive online battles.

To see more Gigabyte Motherboard at Four Star IT checkout our Gigabyte Motherboard Collection

Availability

All Brand

Gigabyte
Laptop Processor Type

Intel
CPU Socket

Intel LGA 1200
Form Factor

mATX
