MSI PRO Z790-A WIFI DDR4 Intel 12th and 13th Gen ATX Motherboard

Original price was: ৳ 38,300.00.Current price is: ৳ 35,500.00.

Highlighting Features

  • Model: PRO Z790-A WIFI DDR4
  • Supported RAM: 4x DDR4, 5333+MHz (OC), Max 128GB
  • Graphics Output: 1x HDMI, 1x DisplayPort
  • Features: 2.5G LAN with Wi-Fi 6E Solution
  • Supported CPU: 12th/13th Gen Core, Pentium Gold & Celeron Processor (LGA 1700)
* অনলাইন থেকে প্রডাক্ট অর্ডার এর পূর্বে হেল্পলাইন থেকে স্টক এবং ডেলিভারী সম্পর্কে সঠিকভাবে জেনে অর্ডার করার জন্য বিশেষভাবে অনুরোধ করা হচ্ছে *

MSI PRO Z790-A WIFI DDR4 Intel 12th and 13th Gen ATX Motherboard Price in BD | Bangladesh

The latest price of MSI PRO Z790-A WIFI DDR4 Intel 12th and 13th Gen ATX Motherboard Price in BD | Bangladesh is 35,500 tk.  You can buy any motherboard at the best price from our official website or visit our showroom.

Visit our Facebook Page or to see more offers visit our Offers Page

To see more product unboxing and first impression videos you can checkout our Official Youtube Channel

Specification

Basic Information
Supported CPU Supports 12th/13th Gen Intel Core Processors, Pentium Gold and Celeron Processors
LGA 1700
Chipset INTEL Z790
Form Factor ATX
243.84mmx304.8mm
Audio Realtek ALC4080 Codec
7.1-Channel USB High Performance Audio
Supports S/PDIF output
Expansion Slots
PCI 3x PCI-E x16 slot
1x PCI-E x1 slot
PCI_E1 PCIe 5.0 supports up to x16 (From CPU)
PCI_E2 PCIe 3.0 supports up to x1 (From Chipset)
PCI_E3 PCIe 4.0 supports up to x4 (From Chipset)
PCI_E4 PCIe 3.0 supports up to x1 (From Chipset)
Memory
Type DDR4
Slots 4 x DIMM
Supported Memory 5333/ 5200/ 5066/ 5000/ 4800/ 4600/ 4533/ 4400/ 4266/ 4000/ 3866/ 3733/ 3600/ 3466/ 3333(O.C.)/ 3200/ 3000/ 2933/ 2800/ 2666/ 2400/ 2133 (By JEDCE & POR)
Max. overclocking frequency:
• 1DPC 1R Max speed up to 5333+ MHz
• 1DPC 2R Max speed up to 4800+ MHz
• 2DPC 1R Max speed up to 4400+ MHz
• 2DPC 2R Max speed up to 4000+ MHzSupports Dual-Channel mode
Supports non-ECC, un-buffered memory
Supports Intel® Extreme Memory Profile (XMP)
Maximum Memory 128GB
Graphics
Graphics 1x HDMI
1x DisplayPort
Support HDMI 2.1 with HDR, maximum resolution of 4K 60Hz
Support DP 1.4, maximum resolution of 4K 60Hz
Connector & Ports
HDMI 1x HDMI
Display Port (s) 1x DisplayPort
USB (s) 2x USB 2.0 (Rear)
4x USB 2.0 (Front)
2x USB 3.2 Gen1 Type A (Rear)
2x USB 3.2 Gen1 Type A (Front)
3x USB 3.2 Gen2 Type A (Rear)
1x USB 3.2 Gen2 Type C (Front)
1x USB 3.2 Gen2x2 Type C (Rear)
LAN Port (s) Intel 2.5Gbps LAN
Wireless Communication module Intel Wi-Fi 6E
The Wireless module is pre-installed in the M.2 (Key-E) slot
Supports MU-MIMO TX/RX, 2.4GHz / 5GHz / 6GHz (160MHz) up to 2.4Gbps
Supports 802.11 a/ b/ g/ n/ ac/ axSupports Bluetooth 5.2, FIPS, FISMA
Supported Storage 4x M.2 slot
M.2_1 (From CPU) supports up to PCIe 4.0 x4 , supports 22110/2280/2260/2242 devices
M.2_2 (From Chipset) supports up to PCIe 4.0 x4 , supports 2280/2260/2242 devices
M.2_3 (From Chipset) supports up to PCIe 4.0 x4 / SATA mode, supports 2280/2260/2242 devices
M.2_4 (From Chipset) supports up to PCIe 4.0 x4 / SATA mode, supports 2280/2260/2242 devices
6x SATA 6G port
RAID Supports RAID 0, RAID 1, RAID 5 and RAID 10 for SATA storage devices
Supports RAID 0, RAID 1, RAID 5 and RAID 10 for M.2 NVMe storage devices
Audio Audio Connectors
Internal I/O Ports 1x Power Connector(ATX_PWR)
2x Power Connector(CPU_PWR)
1x CPU Fan
1x Pump Fan
6x System Fan
2x Front Panel (JFP)
1x Chassis Intrusion (JCI)
1x Front Audio (JAUD)
1x TBT connector (JTBT, supports RTD3)
1x Tuning Controller connector(JDASH)
3x Addressable V2 RGB LED connector (JARGB_V2)
1x RGB LED connector(JRGB)
4x USB 2.0
2x USB 3.2 Gen1 Type A
1x USB 3.2 Gen2 Type C
TPM (Trusted Platform Module ) 1x TPM pin header(Support TPM 2.0)
Others
Special Features 4x EZ Debug LED
Warranty Information
Manufacturing Warranty 3 years

Description

MSI PRO Z790-A WIFI DDR4 Intel 12th and 13th Gen ATX Motherboard

The MSI PRO Z790-A WIFI DDR4 ATX Motherboard supports LGA 1700 CPUs from the Intel Core, Pentium Gold, and Celeron families from the 12th/13th generation. This ATX motherboard, which uses the Intel Z790 chipset and the LGA 1700 socket, includes four DDR4 RAM slots that support twin-channel memory and overclocked speeds of up to 5333 MHz. Six SATA III connectors and four M.2 interfaces provide enough storage capacity and support RAID 0, 1, 5, and 10 through SATA or 0, 1, and 5 via M.2. PCIe 5.0 x16, PCIe 4.0 x16, PCIe 3.0 x16, and PCIe 3.0 x1 slots can be used to install GPUs and other adapter cards. With a 2.5 GbE Intel LAN and Wi-Fi 6E, you can network swiftly and connect to wireless devices quickly. The Realtek ALC4080 audio codec supports 7.1 channel surround sound and has analog and digital output connections on the back. Connect peripherals through two USB 2.0 ports, two USB 3.2 Gen 1 ports, three USB 3.2 Gen 2×2 Type-A ports, or a USB 3.2 Gen 2×2 Type-C port. Video is provided through DisplayPort and HDMI. Internal headers allow front-panel USB 3.2 Gen 2 Type-C and USB 3.2 Gen 1 and 2.0 Type-A ports, RGB connections, chassis intrusion, a TPM module, and other capabilities, as well as a Flash BIOS button on the rear I/O panel. A three-year guarantee is included with the MSI PRO Z790-A WIFI DDR4 13th Gen ATX Motherboard.

To see more Asus Laptops at Four Star IT checkout our MSI Motherboard Collection



All Brand Msi
CPU Socket Intel LGA 1700
